Thornton PA302M amplifier for all types of 4-16 ohm passive speakers

• Operates on both 220V AC and 12V DC power
• Speaker outputs available as 2-8 ohm low-impedance outputs
• MIC input 1 has microphone priority override
• 6.35 mm signal input interface on the front
• MP3 player with SD and USB ports
• Class AB amplifier with 30 W RMS
• Used for all types of 4-16 ohm passive speakers
• Stereo BGM system for home and meeting rooms
• Ideal for small cafes and small supermarkets

About Thornton PA-302M

The Thornton PA-302M is a compact and powerful amplifier designed to deliver high quality sound in a variety of environments. With its ability to operate on both 220V AC and 12V DC power, it is extremely flexible and can be used in a variety of situations.

Design and Construction

The PA-302M has a robust design that is both lightweight and durable. Its compact size means it can be placed almost anywhere, making it ideal for both stationary and portable use. Please note that the device is not waterproof, so it should be used in dry environments.

Inputs and Output Power

The amplifier is equipped with multiple input options, including AUX and two microphone inputs, each with their own volume control. It also has an MP3 player with SD and USB ports, giving users a wide range of options to play their favorite music from various sources.

Technical Specifications

• Output power (RMS): 30W
• Frequency response:
• Microphone: 100Hz-20kHz
• Line: 30Hz-20kHz
• THD at 1 kHz: Less than 1%
• Inputs:
• Input 1, 2 microphone: 5mV
• Input 3 AUX: 245mV
• Output impedance: 4Ω, 8Ω
• Signal-to-noise ratio:
• Microphone: > 70 dB
• Line: > 80 dB
• Power supply: 100-240V (AC 50/60Hz) and 12-16V DC
• Dimensions (WxHxD): 205×65×200 mm

Applications

Home use

This amplifier is perfect for creating an excellent sound experience at home. It can be used to listen to music, watch movies or enjoy karaoke nights.

Commercial Environments

The PA-302M is ideal for commercial environments such as small cafes and supermarkets, where it can be used to create a pleasant atmosphere with background music or to broadcast announcements over the PA system.

Conclusion

The Thornton PA-302M amplifier is a versatile and powerful solution for those looking to enhance their audio environment. With its robust construction, comprehensive features and ease of use, it is an ideal solution for both private homes and commercial environments.
